Standard version:
Motorized operation with manual expansion
Coil hold-down arm for option
Customized version available:
Hydraulic expansion mandrel
Pneumatic coil pressing arm
Coil loading car
Variable speed control
Model | MT-200 | MT-300 | MT-400 | MT-500 | MT-600 | MT-800 | |
Max.width | mm | 200 | 300 | 400 | 500 | 600 | 800 |
Material thickness | mm | 0.35~1.6 | 0.35~1.6 | 0.35~1.6 | 0.35~1.6 | 0.35~1.6 | 0.35~1.6 |
Material inner diameter | mm | 450~530 | 450~530 | 450~530 | 450~530 | 450~530 | 450~530 |
Material outer diameter | mm | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 |
Material weight | kg | 500 | 800 | 1000 | 1500 | 2000 | 2000 |
∗ All the models support customized specifications, please contact our salesperson for more details.
We expect to grow up steadily together with our customers all over the world. and provide better and
better products and services to them.
