Decoiler-Straightener Combo TGL (0.5-4.0mm)

Integrated Compact Design & Cost-Effective Upgrade

The TGL model features an all-in-one structure similar to conventional compact production lines, yet comes at a more budget-friendly price for equipment renovation and upgrading. Built with an integrated uncoiler and straightener structure, it delivers perfect synchronous operation for uncoiling and material leveling procedures.

High Precision & Stable Operation Performance

Equipped with high-precision leveling rollers and a pneumatic top roller lifting mechanism, paired with a high-stability electronic control system, this unit is perfectly suited for processing materials with a thickness ranging from 0.5mm to 4.0mm in uncoiling and straightening applications.

Floor Space Optimized Layout

Unlike traditional coil processing lines that use separate standalone decoilers and levelers, this integrated design effectively eliminates excessive material looping. It greatly cuts down on required workshop space and improves the overall utilization rate of the production area.

Automated Operation & High Safety Level

This combined unit is fitted with internationally compliant electrical control components, featuring self-diagnosis function and emergency stop protection. It ensures operator safety at all times, while also offering simple operation and convenient daily maintenance.

Main Parts Description

Decoiling Section

Optional hydraulic or manual expansion design for coil loading

Pneumatic driven coil pressing arm fitted with PU pressure wheels

Air cylinder powered coil supporting arm to hold and stabilize material coils

Custom heavy-duty uncoiler main shaft with HongEr exclusive design

Pneumatic disc braking structure for stable tension control

Heavy-duty double large roller chain transmission system

Straightening Section

Coil entry swing support arm equipped with auxiliary guide rollers

Handwheel adjustable self-centering limit guide rollers

Premium straightening rollers hardened to HRC60 for long service life

Pneumatic cylinder controlled upper roller opening and lifting

Dual handwheel design for precise roller gap fine adjustment

International standard electrical control configuration
