The hydraulic decoiler machine has stable construction with welded steel for long term service.
The expansion of spindle is hydraulic type.
Variable-frequency drive for variable speed control
Pneumatic hold-down arm for optional
Different loading capacity according to specific coil handling process requirements
Different uncoiling speed for optional: 16m/min uncoiling speed for general metal stamping; 30m/min uncoiling speed for other coil processing line
Model | DBMT-150 | DBMT-200 | DBMT-300 | DBMT-400 | |
Max.Material width | mm | 150 | 200 | 300 | 400 |
Max.load | kg | 500 | 1000 | 1500 | 1500 |
Coil inner diaeter | mm | Ф480~520 | Ф480~520 | Ф480~520 | Ф480~520 |
Max.Coil diaeter | mm | Ф1200 | Ф1200 | Ф1200 | Ф1200 |
Spindle Expansion | Hydraulic Expansion | Hydraulic Expansion | Hydraulic Expansion | Hydraulic Expansion | |
∗ All the models support customized specifications, please contact our salesperson for more details.
